Equipment List
Carefully planned and selected equipment as well as regular maintenance are the base for qualitative and efficient production. We have invested much time and effort, not to mention money,to build up our production lines. With our rigorous maintenance procedures we keep the equipment in excellent shape.
SMT - Line 1 (In-Line) |
| Paste Printing: |
MPM AP/B HiE, with 2D paste inspection and USC |
| Stencil Frame: |
Pneumatic, for frameless stencils |
| Placement: |
SiPlace 80S20, 20.000 cph, 2 pcs
SiPlace 80F4, 10.000 cph
Tape feeders 8-56mm (any pitch) + JEDEC tray holders
Fluxing feeder (for PoP), Label feeder |
| AOI: |
Agilent SJ50 (Pre Reflow) |
| Reflow: |
BTU P-150, 10 + 2 zones, N2-ready |
| Reflow Profiling: |
Super M.O.L.E. Gold |
| AOI: |
Agilent SJ10 (Post Reflow) |
| PCB Handling: |
ASYS, Nutek, Jot |
| PCB Marking: |
IMAJE S8, Bar-Code Labeling (Pick&Place) |
SMT - Line 2 (Off-Line) |
| Paste Printing: |
DEK-247, semiautomatic |
| Stencil Frame: |
Pneumatic, for frameless stencils |
| Placement: |
TWS Quadra, 3.600 cph, 2 pcs |
| Reflow: |
IEMME SMAC, 3 zones |
| PCB Handling: |
Manual (Off line) |
Off-Line |
| Stencil Cleaner: |
Conceptronics Atlantis-CL/W |
| Labels Printers |
Zebra |
THT - Line |
| Component preparation: |
Various machines for lead bending and cutting |
| Insertion: |
Manual placement, 8 places |
| Wave Soldering: |
Speedline Electra 500F |
| Selective soldering: |
ERSA Versaflow dual pot |
| Manual Soldering: |
6 work-stations |
Post Assembling |
| AOI: |
Agilent SJ10 (Off-Line) |
| Visual inspection: |
Various microscopes (Mantis, Leica, Zeiss) and magnifiers |
| Testing, general: |
Standard test equipment (TEK scopes, PSU, etc) |
| Functional testing: |
According to customer specifications |
| ICT: |
Test fixtures (vacuum) |
| Programming: |
Various programming solutions |
| BGA Rework: |
PACE TF2000 BGA Rework Station |
| Rework: |
DENON De-soldering guns
Quick 858 Hot Air
MARTIN Hot Plate-03 |
Mechanical |
| CNC: |
SUDA SD-8070 CNC Machine |
| Potting: |
2-component mixer with dosimeter |
| Al-profile cutting: |
Saw 250mm, custom made |
| Pad Printing: |
LC-PM2-150, 2 colors, open system |
|
